Description
Main ParametersBM1204-4NDrive Type4×4 Four-wheel driveEngine Brand / Emission StandardYuchai National IVEngine ModelYCF36140-T482Max Torque (N·m) / Speed (rpm)520/1300-1600No. of Cylinders / Displacement (L)4/3.621Fuel Tank Capacity (L)140/220 (140+80)Rated Power / Corresponding Speed (kW/rpm)88.2/2
Product Parameters
| Main Parameters | BM1204-4N |
| Drive Type | 4×4 Four-wheel drive |
| Engine Brand / Emission Standard | Yuchai National IV |
| Engine Model | YCF36140-T482 |
| Max Torque (N·m) / Speed (rpm) | 520/1300-1600 |
| No. of Cylinders / Displacement (L) | 4/3.621 |
| Fuel Tank Capacity (L) | 140/220 (140+80) |
| Rated Power / Corresponding Speed (kW/rpm) | 88.2/2200 |
| Rated Power Fuel Consumption (g/kW·h) | ≤235 |
| Aspiration Type | Turbocharged and intercooled |
| Air Filter | Dry-type air filter |
| Torque Reserve | ≥20% |
| Transmission System | |
| Clutch | Dry-type, 12-inch, dual-action |
| No. of Gears | 12F+12R |
| Shift Type | Mechanical dog clutch / synchronizer shift |
| Maximum Speed | 34.81 km/h |
| Gear Layout | Side-mounted |
| Hydraulic System | |
| Hydraulic Output Flow (L/min) | 57 |
| Hydraulic Output Valve Group | 2 groups / 3 groups hydraulic output |
| Working Device | |
| Three-point Linkage Category | 2/3 |
| PTO Speed | 540/760, 540/1000 (optional), 760/850 (optional) |
| Lifting Force (at 610mm) | ≥22 kN |
| Tillage Depth Adjustment | "Position control, float control (mechanical high-pressure lift linkage) Force control / position control (electronic high-pressure lift linkage)" |
| Overall Parameters | |
| Overall Dimensions (L×W×H) (mm) | "4410×2160×2780 (cab top) 4410×2010×2750 (safety frame top)" |
| Min. Operating Weight (kg) | 4000 (with cab) / 3850 (without cab) |
| Wheelbase (mm) | 2180 |
| Min. Turning Radius (m) | 3.8 |
| Rated Traction Force (kN) | 24.5 |
| Min. Ground Clearance (mm) | 460 mm (middle of front axle bottom) |
| Air-conditioned Cab | Optional |
| Heater Cab | / |
| Front/Rear Wheel Track (mm) | "Front: 1560, 1610, 1660, 1760 (commonly 1560) Rear stepless adjustable: 1560-1820 (commonly 1560) Rear stepped adjustable: 1560, 1635, 1750, 1820 (commonly 1550)" |
| Tire Specification | "Standard tires: 11.2-24/16.9-34, 9.5-24/16.9-30 Paddy tires: 9.5-24/16.9-30, 11.2-24/16.9-30, 9.5-24/14.9-30 Radial tires: 280/85R24-460/85R30" |
| Brake and Steering | |
| Brake System | Wet disc brake, mechanically controlled |
| Steering Type | Full hydraulic steering |
| 4WD Steering Angle | 46° (standard tires) |
