Description
Main ParametersBM2204-7NDrive Type4×4 Four-wheel driveEngine Brand / Emission StandardYuchai National IVEngine ModelYCA07P250-T401Max Torque (N·m) / Speed (rpm)770/1500-1700No. of Cylinders / Displacement (L)6/6.871Fuel Tank Capacity (L)Main tank 270 + Auxiliary tank 160Rated Power / Corresponding S
Product Parameters
| Main Parameters | BM2204-7N |
| Drive Type | 4×4 Four-wheel drive |
| Engine Brand / Emission Standard | Yuchai National IV |
| Engine Model | YCA07P250-T401 |
| Max Torque (N·m) / Speed (rpm) | 770/1500-1700 |
| No. of Cylinders / Displacement (L) | 6/6.871 |
| Fuel Tank Capacity (L) | Main tank 270 + Auxiliary tank 160 |
| Rated Power / Corresponding Speed (kW/rpm) | 161.8/2300 |
| Rated Power Fuel Consumption (g/kW·h) | ≤225 |
| Intake Method | Turbocharged & Intercooled |
| Air Cleaner | Dry type air filter |
| Torque Reserve | 14% |
| Transmission System | |
| Clutch | Single-plate, Dry type, 14-inch |
| No. of Gears | 24F+12R / 16F+12R Creeper / 16F+12R Micro-creeper / 12F+12R (Optional) |
| Shifting Method | Synchromesh gear shifting |
| Max Speed | 38.84 km/h |
| Gear Layout | Side-mounted |
| Hydraulic System | |
| Hydraulic Output Flow | 76.8/93.2 L/min |
| Hydraulic Output Valve Groups | 3 groups / 4 groups optional |
| Working Equipment | |
| Three-point Linkage Category | Category 2 / Category 3 |
| PTO Speed | 540/1000, 760/850, 750/1000 multi-speed optional |
| Lifting Capacity (at 610mm) | 52 kN |
| Tillage Depth Adjustment | Pressure, Position & Float control |
| Overall Machine Parameters | |
| Overall Dimensions (Single Tire) (L×W×H)(mm) | 5350×2510×3207 |
| Overall Dimensions (Dual Tires) (L×W×H)(mm) | 5350×3780×3207 |
| Min. Operating Weight (Single Tire)(kg) | 7370 |
| Min. Operating Weight (Dual Tires)(kg) | 8090 |
| Wheelbase (mm) | 2805 |
| Min. Turning Radius (m) | Single-side braking 5.5±0.2 / Dual-side braking 6.3±0.2 |
| Rated Drawbar Pull (kN) | 61 |
| Min. Ground Clearance (mm) | 480 mm (Bottom of main/auxiliary tank connecting pipe guard) |
| Air-conditioned Cab | Standard |
| Front/Rear Wheel Track (mm) | Front: 1680, 1720, 1770, 1830, 1880 1900, 1950, 2010, 2060 (Commonly 1900) Rear: 1796, 1826, 1866, 1876, 1896, 1906, 1946, 1976, 2196, 2226, 2266, 2296 (Commonly 1866) Rear Dual Tires: 1874-3236 |
| Tire Specification | Radial F: 420/85 R28 - R: 520/85 R38; Bias F: 16.9-28 - R: 20.8-38 Bias F: 18.4-26 - R: 20.8-38; Radial F: 480/70 R28 - R: 650/65 R38 Rear Dual Bias: F: 16.9-28 - R: 20.8-38 Rear Dual Radial: F: 420/85 R28 - R: 520/85 R38 |
| Braking & Steering | |
| Braking System | Independent / Multi-disc / Oil-bath / Hydrostatic |
| Steering Method | Full hydraulic steering |
| 4WD Steering Angle | 52° |
