Description
Main ParametersBP2804-8NDrive Type4×4 Four-Wheel DriveEngine Brand / Emission StandardYuchai, China Stage IVEngine ModelYCA08300-T400Max Torque (N·m) / Speed (rpm)1206/1300-1600No. of Cylinders / Displacement (L)6/7.525Fuel Tank Capacity (L)Main Tank 425 + Auxiliary Tank 117Rated Power / Correspondi
Product Parameters
| Main Parameters | BP2804-8N |
| Drive Type | 4×4 Four-Wheel Drive |
| Engine Brand / Emission Standard | Yuchai, China Stage IV |
| Engine Model | YCA08300-T400 |
| Max Torque (N·m) / Speed (rpm) | 1206/1300-1600 |
| No. of Cylinders / Displacement (L) | 6/7.525 |
| Fuel Tank Capacity (L) | Main Tank 425 + Auxiliary Tank 117 |
| Rated Power / Corresponding Speed (kW/rpm) | 206/2200 |
| Rated Power Fuel Consumption (g/kW·h) | ≤225 |
| Intake Type | Turbocharged & Intercooled |
| Air Cleaner | Dry-Type Air Filter |
| Torque Reserve | 32% |
| Transmission System | |
| Clutch | Wet-Type Clutch |
| Number of Gears | 40 Forward + 40 Reverse |
| Shift Mode | Power Shift + Synchromesh Shift |
| Maximum Speed | 40 km/h |
| Gear Layout | Side-Mounted |
| Hydraulic System | |
| Hydraulic Output Flow | 121 L/min |
| Hydraulic Output Valves | 4 Groups |
| Working Equipment | |
| 3-Point Hitch Category | Category 3 |
| PTO Speed | 540E/1000 |
| Lift Capacity (at 610 mm) | 76.9 kN |
| Tillage Depth Control | Integrated Control (Position, Float, Draft Integrated Control) |
| Overall Machine Parameters | |
| Overall Dimensions (Single Tires) (L×W×H) (mm) | 6120×2715×3400 mm (Top of Cab) |
| Min. Operating Weight (With Cab) (kg) | 9550 |
| Min. Operating Weight (Without Cab) (kg) | / |
| Wheelbase (mm) | 3120 |
| Min. Turning Radius (m) | 10±0.2 |
| Rated Traction Force (kN) | 51.9 |
| Min. Ground Clearance (mm) | 440 (Bottom of Drawbar) |
| Air-Conditioned Cab | Standard |
| Heated Cab | / |
| Front/Rear Track Width (mm) | Front: 2040, Rear: 2000 |
| Tire Specification | Radial Tires: Front F: 600/65R34, Rear R: 710/70R38 |
| Brake & Steering | |
| Brake System | "Multi-Disc - Oil Bath / Hydraulic Boost Power; Independent / Multi-Disc - Oil Bath / Hydrostatic" |
| Steering Mode | Full Hydraulic Steering |
| 4WD Steering Angle | 25° |
